Three unbound values

Across 0.31.0 and 0.32.0 we fixed three soundness failures found in our own prover. Two are total breaks: a malicious prover produces a proof for a false statement and the real verifier accepts it. Both were confirmed with a proof-of-concept prover against the shipped pipeline, not argued on paper.

§ Summary

1. The Brakedown row code delivered single-digit-bit soundness while the configuration claimed 128. A sparse expander's minimum distance is capped by the column weight of its generator. A codeword-aware forgery against the real prove/verify pipeline accepted at up to 54% per attempt. Affects every table, including pure-AIR tables with no bus. Fixed by replacing the row code with MDS Reed-Solomon over an additive binary-field FFT; the forgery harness now records zero acceptances. Fixed in 0.31.0.

2. The LogUp fraction helper h was never committed. A prover fits its evaluation after the challenge is drawn, the final check collapses to 0 = 0, and every constraint on the table (AIR, boundary, bus) goes unenforced. Deterministic, not probabilistic. Affects every table carrying a permutation or lookup bus: every shipped circuit except the Fibonacci and arithmetic examples. Fixed by committing h and binding each h_eval to its opening. Fixed in 0.32.0.

3. A table declaring no bus could inject an unbound claimed_sums entry into cross-bus matching. Forges bus cancellation in characteristic two. Our shipped circuits declare a bus on every table and were not affected; the gap is live for any program pairing a bus-free table with a real bus. Fixed verifier-side with no change to proof bytes. Fixed in 0.32.0.

§ Affected versions

0.31.0 replaced the row code and changed the transcript; 0.30.0 proofs and bundles neither verify nor deserialize. 0.32.0 adds the h commitment and moves the wire format to v3; v2 proofs are rejected. Both upgrades require re-proving. The zero-bus fix is verifier-only and changes no proof bytes.

Upgrading is mandatory for any deployment relying on the 128-bit security claim.

This is written for people building proof systems. The bugs are ours, but the class is not, and the first is a property of a code family several implementations use.

§ The common shape

Every one of the three has the same structure: a value entered the final verdict and nothing bound it to the committed witness.

The reasons it was unbound differ, and that is the useful part:

1. The row code's minimum distance was assumed rather than derived. Its statistical binding was far weaker than the security parameter claimed.
2. h_eval was never committed at all.
3. claimed_sums was bound by code sitting behind a condition that did not hold.

None of these is a mistake in the underlying cryptography. Each was locally reasonable. What was missing was an accounting discipline: for every quantity that reaches the final check, be able to name the thing that binds it. We could not, because we had never written the list down.

§ 1. The row code's distance was a heuristic

Fixed in 0.31.0.

Reach: the proximity layer, and through it every table, including the pure-AIR tables that the other two bugs do not touch.

Our Brakedown row code was a sparse expander. Its minimum distance is capped by the column weight of the generator. That cap is a structural property of the construction, not a matter of parameter tuning, and the proximity check consequently delivered single-digit-bit soundness while the configuration claimed 128.

A codeword-aware forgery run against the real prove/verify pipeline accepted at up to 54% per attempt.

We replaced it with an MDS Reed-Solomon code over the additive binary-field FFT subspace chain. Relative distance is now exact Singleton, δ = (encoded_width − support − grid_cols) / encoded_width, and the proximity bound (1−δ)^q holds with num_queries = 176. The security gate runs per table, main trace and every chiplet at its own geometry, rejecting anything that delivers under 128 bits before verification proceeds. The forgery harness now records zero acceptances.

The change did not stay local, and this is the part worth knowing before you attempt it. Our virtual bit-packing extracted bit-planes during the proximity fold. Bit extraction is GF(2)-linear, which commutes with an expander's XOR fold but not with Reed-Solomon twiddle scaling, which is GF(2^k)-linear. Under MDS an honest prover would fail roughly δ of its own proximity queries. The bit-plane collapse has to happen before the code layer, and that reduction is the ring-switch of Diamond-Posen (eprint 2024/504, Construction 3.1): reduce each packed column's bit-plane claims to one whole-column claim, then fold whole physical columns, which does commute. The bit-mixing challenge is drawn after the claims are absorbed, and Schwartz-Zippel over it binds every bit-plane to its committed column, closing the lossy-collapse gap noted in Remark 3.3 of that paper.

Zero-knowledge moved at the same time. The old scheme appended noise columns to a systematic encode. The new encode is non-systematic and carries a random support block of ldt_support_size symbols (default 200, floored at num_queries) inside the message, at coordinates disjoint from the data. Any num_queries opened columns are jointly uniform, and no committed column contains cleartext witness symbols. The evaluation claim reads the data half alone, and the support cancels without costing soundness.

§ 2. The uncommitted LogUp helper

Fixed in 0.32.0. Live in 0.31.0 and earlier.

Reach: every table carrying at least one permutation or lookup bus. In our tree that covers the entire general-purpose path (CPU↔RAM/ROM/Keccak/AES/IntArith links, offline memory consistency, table range checks) and every shipped circuit except raw Fibonacci and inline Keccak.

LogUp introduces a fraction helper h[i] = s[i] / (γ + key[i]). Our proof carried no commitment to h. The verifier read each bus's h_eval as a raw scalar from the proof and fed it into the bus contribution term, which is affine in h_eval with coefficient alpha_bus · ((γ + key)·eq_zc + eq_lookup), generically nonzero. The entire verdict is one scalar equation, val_final == expected_val.

The ordering finished it. h_evals were absorbed into the transcript after the sumcheck had drawn r_final. A prover picks h_eval with both r_final and val_final already known, and solves the final check for it.

The forgery:

1. Commit an arbitrary false trace: bus relation violated, AIR still satisfied.
2. Report claimed_sums = 0; cross-bus matching then cancels trivially.
3. Send an all-zero sumcheck, giving val_final = 0.
4. Fit h_eval = s_eff·eq_zc / ((γ + key)·eq_zc + 1) from the committed trace evaluations at r_final. In characteristic two the contribution cancels as A + A = 0.
5. Open the honestly committed trace at r_final. The verifier accepts.

The consequence is wider than the multiset argument it was supposed to protect. A free h_eval absorbs the whole gap between val_final and expected_val. Every constraint on a bus-carrying table (AIR, boundary, bus) went unenforced, not only the multiset relation. The bug reads like a lookup-argument problem and is actually a complete loss of soundness across most of the circuit surface. Unlike the proximity break above, this one is deterministic: the prover succeeds every time.

There is no algebraic shortcut for the fix. h(r_final) is rational in the trace (s/(γ + key)), and no recomputation from the opened trace evaluations exists. A polynomial commitment is mandatory. We now commit h in a second round drawn after γ and β, absorb its root before α, open h at r_final, and reject unless every reported h_eval equals the opened value. Presence is validated against the trusted bus specification, which stops the binding from being dropped: h_commitment and h_eval_proof are present exactly when the table declares a bus, and the commitment's dimensions must match the table height and bus count.

§ 3. The zero-bus injection

Fixed in 0.32.0. Live in 0.31.0 and earlier.

Reach: any program pairing a table that declares no permutation bus with a table that has a real one. Our shipped circuits declare a bus on every table and were not affected. Program::permutation_checks defaults to empty, which makes the vulnerable shape any AIR that does not override it: a range helper, a driver main trace, a chiplet bound only by boundary constraints.

The LogUp auxiliary validation (length checks on claimed_sums and h_evals, plus the per-endpoint bus_id ordering check) was gated behind if !bus_specs.is_empty(). For a table with no declared bus those checks were skipped. The same condition gated entry into the sumcheck initial claim and the r_final consistency term, leaving claimed_sums bound to nothing on the trace.

But it was still absorbed into the transcript, and still harvested by cross-bus matching, which groups endpoints by bus_id string and never checks that the identifier was declared by the program.

Cross-bus cancellation requires the per-bus_id sum of every endpoint's claimed_sum to be zero. A zero-bus table's unbound vector is a free term on that sum. Forge an imbalance δ on the real bus, inject (real_bus_id, δ) through the bus-free table, and in characteristic two the total cancels: δ + δ = 0.

The fix is one line of control flow: run the checks unconditionally, forcing a zero-bus table to present empty vectors. Verifier-only; proof bytes and transcript are unchanged and every existing proof still verifies.

This one matters because it is boring. The binding logic was correct and present. It was skipped by a guard that looked like an optimization.

§ What correctness cost

§ 0.31.0, the MDS row code

Measured on the signed public cdylib 0.8.0, table-math, Apple M3 Max, -C target-cpu=native. Peak memory is phys_footprint_peak rather than ru_maxrss, because the macOS compressor caps the resident set under pressure.

Against the previous release:

• Proof size +15-50%, with AES at roughly 2.2x, the most commit-bound workload with the largest chiplet tables.
• Peak memory 1.4-1.7x, from the encoded matrix at rate 1/2.
• Prove time within ±12%, except AES at +32%.

Three prover-internal optimizations landed in the same window and bought 15-29%; the MDS encode spent most of it back where commit dominates. Verification stays flat, 5.6 ms to 71 ms from 2^15 to 2^24 rows.

§ 0.32.0, the h commitment

The binding adds a commitment and an opening per bus-carrying table. Proof growth scales with bus count rather than trace width, and the opening is base-only, which halves its row width. h is an all-B128 table with no transition constraint, and the verifier parses one value per committed column, dropping the next-row shift. Peak memory is roughly flat. Full measurements ship with the release.

Those are the honest numbers. Some of our earlier published figures were faster because the prover was skipping work that soundness requires. A benchmark from a system that accepts forgeries at 54% is not a benchmark.

§ For other implementers

Four things generalize beyond our tree.

Derive code distance; do not inherit it. If your PCS soundness rests on a relative distance, that distance needs a bound you can state, not a construction you assume is good. A sparse expander's minimum distance is capped by generator column weight, and the gap between that cap and our intended security parameter ran to roughly two orders of magnitude in bits.

Enumerate what binds each value. For every quantity entering the final check, write down the mechanism that ties it to the committed witness: a commitment and opening, a sumcheck claim, a transcript ordering constraint. If the entry is blank, that value is free. Ours were blank in two places and neither was visible without the list.

Watch ordering against the transcript. h_eval was fatal specifically because it was absorbed after r_final was drawn. A value the prover supplies after seeing the challenge that its check depends on is a solved equation, not a claim.

Guards that skip validation are attack surface. The empty-bus_specs case looked like a table with nothing to check. It was a table whose checks were skipped while its data still flowed into a global sum.

§ Scope

This postmortem covers hekate-verifier, hekate-core, hekate-program, hekate-crypto and the wire format, all of which are open. The prover-side encode lives in a closed repository and reaches the open workspace as a signed cdylib. Soundness is a property of the verifier and the protocol, both public, and the forgeries above were run against the shipped pipeline end to end.
