One support cell short

In 0.35.0 and 0.36.0, a zero-knowledge proof could confirm a guess of its own witness. Both releases committed the LogUp helper columns of every bus-carrying table under Merkle leaves without salts, and on every table whose grid has at least 2^11 columns they gave each message 287 random support cells, as many as the verifier draws columns. On a proof whose 287 draws for such a table were pairwise distinct, every leaf of that table's helper tree, and its root, followed from the table's bus keys and what the proof shows. Anyone holding a candidate for those keys could check it offline.

The gap leaves soundness alone: it concerns what a valid proof reveals, and no forgery follows from it. No shipped example is recoverable either, because the smallest private input behind any exposed table is a 256-bit seed. What failed is the zero-knowledge guarantee itself. A statement about a short secret, such as a PIN, a password or a choice among a few options, could be recovered by enumeration from any proof that exposed a table carrying it.

0.37.0 commits 288 support cells over 287 queries, and with a nonzero security floor both parties reject a support that does not exceed the query count. The fix costs one field element per proof.

For readers new to this series: Hekate commits a table by encoding each message, S random support cells followed by L data cells, into a Reed-Solomon codeword of W symbols. The verifier draws t of the W columns at random, opens them and checks them against a folded vector the prover sends. Each column of the encoded matrix is one Merkle leaf, the hash of its symbols. In 0.35.0 and 0.36.0 the LogUp helper columns h = s / (gamma + key) of a bus-carrying table sat in a tree of their own, opened at the same columns as the table's trace.

§ Summary

Gap 1 is the mechanism and gap 2 the same mechanism on a rarer shape. Gap 3 is why it shipped: every statement of the rule was true of the symbols the verifier opens, and none mentioned the leaves of the columns it leaves closed.

§ Affected versions

Releases before 0.31.0 hid the witness with a different encoding, which this postmortem does not examine.

No proof crosses this boundary. ldt_support_size is absorbed into the transcript before any challenge and it moved, which means a 0.36.0 proof fails replay at the first challenge. The proof wire format moves from v6 to v7, carried by the pooled commitment shipping alongside, which puts every table under one tree per oracle. The pinned prover release is 0.15.0.

Upgrading protects new proofs only. A proof already published under 0.35.0 or 0.36.0 keeps its root and its sibling digests and, where its draws for a table were distinct, stays checkable against a guess of its witness.

The third row states a limit. Proved: with one support cell more than the query count, the symbol of every message at every unopened column is uniform given the view and every data cell, unless fewer than two messages carry nonzero weight in the fold, which happens with probability below 2^-118 on every example. Not examined here: the linear part of the view, which rests on the blinds and on the outer argument, and the outer argument's own oracles.

§ Where this one sits

The five postmortems before this one were about soundness. This is the first about zero knowledge, and two of them already state the rule it corrects.

The 0.32.0 postmortem described the support block, which shipped in 0.31.0, and what it buys: "Any num_queries opened columns are jointly uniform, and no committed column contains cleartext witness symbols." Both halves hold at S = t. The 0.35.0 postmortem restated the rule as that release raised the query count: "The support block hiding opened columns must be at least as large as the query count." Also true, of the opened columns. The README says the tree covers "encoded columns only (raw trace never hashed, true ZK)". A column whose randomness the view pins is the raw trace under a public affine map, and its hash hides nothing a guess cannot reach.

§ 1. At S = t the helper tree's leaves were fixed

A message is a support xi of S cells and data d of L cells, and its symbol at a point alpha of the codeword domain is sum_{k<S} xi_k X_k(alpha) + sum_{k<L} d_k X_{S+k}(alpha), where X_k is the novel polynomial basis and deg X_k = k. When S = t and all t draws are distinct, the S x t matrix (X_k(alpha_j)) is invertible, since a nonzero polynomial of degree below S has fewer than S roots. The support is then an affine function of the data and the opened symbols, and every other symbol of the message follows.

The helper tree holds one column per bus endpoint on the table's grid. The table's bus keys and selectors, with the public challenges gamma and beta, fix every data cell. 0.35.0 and 0.36.0 placed the blinds in the trace tree, one blind column per table and one more for ring-switched units, and gave the helper tree none. Its messages were a support and helper data, and nothing else.

Leaf j hashes 0x00 and the symbols of every helper message at column j; an inner node hashes 0x01 and its two children. A guess of the bus keys therefore yields the helper data, the support of every message, every unopened symbol, every leaf and the root. The root is in the proof, and the octopus multiproof sends more: the digest of every unopened sibling of an opened leaf, up to 287 per tree. A guess can be tested against any one of them.

The verifier draws the 287 column indices uniformly with replacement. When two draws coincide, fewer than S columns open, each message keeps a free support cell and the leaves hide. A table was exposed exactly on the proofs whose draws were pairwise distinct:

Tables at split c >= 11 ran S = 287 at W = 2L. Narrower grids ran L support cells, 512 or 1,024, at W = 4L, and were not exposed. A table with no bus has no helper tree.

§ 2. A trace on one grid row without ring units

The trace tree carries uniform cells: its blind column. On a table whose grid has one row and no ring-switched units, that blind is a single message, and the fold vector fixes its data, which enters the fold with a public nonzero coefficient beside terms the witness determines. At S = t its support follows as in gap 1, and the whole trace tree is fixed by the table's witness and the view. One shipped table has this shape, the ML-KEM-768 receiver's main table at 2^11 rows, exposed on about 1 proof in 28,600. A second grid row or a ring unit leaves the trace tree free cells at any support size.

§ 3. The rule counted the opened columns

Every statement of the hiding rule was about the symbols the verifier opens. The configuration check rejected ldt_support_size < num_queries under the comment "opened columns exhaust the noise budget and witness data leaks". The two postmortems above said the same. At S = t, the t opened symbols of a message are a bijective image of its support and carry nothing about its data. The other W - t columns reach the verifier through their leaves, and no statement counted them.

§ What a proof exposed

Measured on 0.36.0 and its pinned prover release 0.14.0, the fifteen example workloads with zero knowledge on, and the verifier logging each table's geometry and its count of distinct draws:

In that run, the proofs of ML-DSA-87, AES-128, AES-256 and SHA-256 at 2^21 rows each had a helper tree with 287 distinct draws. Every RSA-2048 table has at most 2^10 rows and ran 512 or 1,024 support cells. The ML-DSA examples prove verification, with the public key and the signature as witness.

A test costs little. Once per proof, the attacker inverts the S x S matrix of the opened points, about 24 million multiplications in GF(2^128). Per guess, it computes the table's helper values, M (L + t) multiplications for the symbols of the M helper messages at one sibling column, and one hash of 16 M + 1 bytes. Across the exposed tables of the examples that runs from 2,335 multiplications, on the ML-KEM-768 sender's Keccak table, to 4.2 million on SHA-256 at 2^21 rows. A guess that changes u key cells updates in O(u) field operations per helper column and one hash.

§ How we found out

The gap surfaced during work on our note on the pooled commitment. The check against shipped code ran on 6 October 2026. The configuration, leaf hash and query draw were read at the 0.35.0 and 0.36.0 tags, and the pinned prover releases 0.13.0 and 0.14.0 from their source. The fifteen example workloads were then proved on 0.36.0 with prover 0.14.0, the verifier logging per table its split, support size, helper column count and distinct draws.

§ How the fix is checked

Configuration. Config::prod() sets 288 support cells over 287 queries. check_security rejects ldt_support_size <= num_queries with InsufficientSupport whenever min_security_bits > 0, and the verifier runs it on the pool's shape before it reads an opening. support_below_queries_rejected and support_equal_to_queries_rejected in hekate-core/src/config.rs pin the rejection below and at the query count. The prover runs the same check on the same shape.

Leaves at S = t + 1. Polynomials of degree below S >= t + 1 interpolate any t + 1 values, and the symbol at an unopened point is independent of the opened ones. The fold vector reveals one linear combination of the supports. When two messages carry nonzero weight in it, every unopened symbol of every message stays uniform given the view and every data cell. Every pool has a data slot and a blind slot per table, whose weights are nonzero polynomials in the challenges; the condition fails with probability below 2^-118 on every example.

Reconstruction. At toy scale (c = 4, W = 32, t = 6, a table of 2^6 rows with two buses), the helper tree's leaves and root rebuild exactly from the witness and the six opened symbols at S = t, and a flipped witness bit misses. At S = t + 1, and at S = t with one repeated draw, two supports agreeing on every opened symbol give two different roots.

§ What correctness cost

One support cell per message. The fold vector grows by one element, 16 bytes on the wire per proof under the pooled commitment. Each message grows by one cell in 4,384 at the narrowest deployed grid, c = 12. The code length does not move at any deployed split, and the query term moves by under 0.1 bit.

§ What changed for circuit authors

Nothing in the API. Config::prod() carries the new support size.

Custom configurations. A Config with ldt_support_size <= num_queries now fails on both sides with ldt_support_size (N) must be > num_queries (M) whenever min_security_bits > 0. Config::dev() waives the floor and proves without zero knowledge.

Everything re-proves. The support size is transcript-bound and it moved.

§ What this release does not promise

Published proofs. Upgrading does not reach a proof published under 0.35.0 or 0.36.0.

Zero knowledge at a zero security floor. min_security_bits = 0 skips the support check, also with zero knowledge on.

A complete zero-knowledge proof. The leaves are covered by the argument above. The linear part of the view rests on the blinds and on the outer argument, whose zero knowledge is argued separately, and this postmortem revisits neither.

Independent audit. This workspace has not had one.

§ For other implementers

Count every symbol the verifier can recompute. A support of S cells hides t opened symbols at S = t. An unsalted leaf of an unopened column is in the view too, through the root and the multiproof, and hides only when each message keeps a free cell after the openings: S >= t + 1, or a salt per leaf.

A tree without blind rows has only its support. Helper and lookup columns are functions of the witness and public challenges, and their tree inherits nothing from the trace tree's blinds.

Repeated draws are no margin. Exposure needs distinct draws, and at large widths they are the common case: 73 percent of proofs at W = 2^17.

A multiproof ships digests of unopened leaves. A guess can be tested against any one of them.

A spare cell or a salt per leaf. Salts cost t per opening. The spare cell costs one element of the fold vector, and we took it.

§ Scope

The previous postmortems are at postmortem-0.36, postmortem-0.35, postmortem-0.34, postmortem-0.33 and postmortem-0.32.

This one covers hekate-core, hekate-program, hekate-crypto and hekate-verifier, all open. The prover reaches this workspace as a signed shared library built from a closed repository. The facts used here about its commitment, a support slot in every message and a helper tree without a blind column, are visible through the opening format the verifier enforces: every opened helper column parses as exactly its symbols. The exposure figures come from 0.36.0, its pinned prover release 0.14.0, and a verifier that additionally logs each table's geometry and distinct draw count.
