Shapes the honest prover never builds

The 0.32.0 postmortem carried an affected-versions table whose last row read 0.32.0 | none known | Current. That was true of the protocol and false of the circuits. Within the next two weeks we found seven soundness gaps across the Keccak and AES chiplets, each one sufficient on its own to break the guarantee the chiplet exists to provide.

Both chiplets computed their round functions correctly. Neither proved its cipher.

§ Summary

Sixteen forgery tests were written against these, seven on Keccak and nine on AES. Each one is a consistent witness rather than a tampered cell, laid out under its own substitution and run through the real prove and verify pipeline. Six of the nine AES forgeries were run against a pre-fix build and confirmed accepted by the shipped prover and verifier. The other three, and all seven on Keccak, were constructed alongside their fix and have only ever run against the fixed AIR. Those demonstrate that the fix rejects the shape. They are not independent confirmations that the shape was once accepted. All sixteen are rejected now and none is #[ignore]. A seventeenth test holds the door open on purpose: it builds a host carrying four of the five roots that pin the emit direction, and that host still accepts.

§ Affected versions

The wire format has moved three releases running: v2 in 0.31.0, v3 in 0.32.0, v4 here. Each rejects its predecessor. Whatever version you are on, reaching 0.33.0 means re-proving, and no proof crosses any of those boundaries.

That last row states coverage instead of absence, which is the one difference between this table and the one it follows. Checked: the control-plane language of both chiplets is enumerated and equals the honest automaton, and the host-side direction pin is checked the same way. Not checked: the data plane is not enumerated at all, and a bus key is examined only for clock ownership, where even that examination accepts a written waiver in place of a clock. Nothing asks whether two emissions can collide on a key, or whether a key distinguishes emissions the AIR treats differently. Three of the seven gaps below sit in that unchecked region and we found them by reading.

The Keccak gaps reach every SHA-3 and SHAKE statement proved against the chiplet, which includes ML-KEM-768 and ML-DSA-65, both of which absorb through it. The AES gaps reach every AES-128 and AES-256 statement. A counter-mode host is the worst case for gap 4: the keystream is exactly what the chiplet exists to prove and exactly what a bare emit row makes free.

Neither fix touches the wire format, Config, or transcript ordering. What changes is the committed column layout on both chiplets and on the S-box ROM, and with it program_id for any program embedding them. Existing proofs are rejected and must be re-proved against a prover release built for the new layout; the pinned prover cdylib release for 0.33.0 is 0.11.0.

0.33.0 carries one further change that is not a soundness fix and closes no gap here: the Brakedown commitment layout, which moves the wire format to v4. It is described with its measurements at the end of the cost section.

Upgrading the crates is not sufficient by itself. Both fixes have a host-side half, and a host that takes the new crates without migrating its own AIR has closed gaps 1, 2, 4, 5 and 7 and left 3 and 6 open. Some of that migration is caught by the compiler and some of it is not: CpuAes256Unit::linking_spec_at gains a third parameter, which will not build, while a Keccak host that neither anchors its direction column nor writes it correctly compiles and proves and is still forgeable. See The half of the fix that lives in the host below.

§ What the seven have in common

Every value here was committed and opened, which is what puts these seven in a different class from the previous three. Those were values reaching the verdict with no commitment behind them at all. Here the commitments are real, the roots fire, and the openings verify. What is missing is a constraint saying what a committed column may hold, and a bus key rich enough to tell two emissions apart. Naming the mechanism that binds each value entering the verdict, the discipline the last postmortem ended on, returns a clean sheet on all seven of these.

Each AIR was a faithful description of a well-formed block, and a faithful description of the honest witness is not a proof that every emission belongs to one. That splits three ways:

A constant living in a witness column is a free variable. Keccak's iota constants were 64 committed bit columns that the round equation read and no root touched. AES's round counter is the same failure wearing different clothes: it pinned a value on the final row rather than a count of rows, and a value has more than one preimage.

An AIR that constrains the interior of a block does not constrain its boundary. Both chiplets said what follows a round row and what precedes an emit row. Neither said where a run may open, and AES did not say that a run must close. A prover who may choose where a chain begins chooses its input; a prover who may choose where it ends chooses its round count.

A bus key is the whole interface. Anything absent from the key is not proved about the emission. Direction was absent twice. A clock was absent once, and in characteristic two an even multiplicity is not a weak binding, it is a deletion: the pair cancels before cross-bus matching runs and the columns it carried go back to being free.

§ 1. Keccak: the round schedule was a witness

RC_BITS was 64 committed bit columns. The Iota equation read them and nothing pinned them to FIPS 202. The root count was 25 packing + 1600 round + 2 Ghost Protocol + 2 selector boolean, and none of those 1629 roots touched the column. That was visible from a count, and we did not do the count.

The round constraint is next_bit = chi + rc_bit on lane (0,0), which puts the constant on the output side. The last round row's constant therefore sets lane (0,0) of the block's final state outright. Twenty-four free 64-bit constants give 1536 bits of freedom over a 1600-bit output. For SHA3-256 the digest is lanes 0 to 3, and lane 0 alone is enough: pick the target value, solve for the round-23 constant, lay an otherwise honest chain.

Fixed by replacing the constant column with a one-hot round index the AIR drives. ROUND_BITS: [Bit; 32] expands from one committed B32. Iota reads it as a coefficient sum: for each bit z, the rounds whose constant sets z contribute their selector, and the constant never appears as a witness at all.

§ 2. Keccak: a chain could open anywhere

Two constraints carried the whole chain discipline:

cs.constrain(s_round * (one + next_s_round + next_s_in_out));
cs.constrain(next_s_in_out * (one + next_s_round) * (one + s_round));

A round row is followed by a round row or an output row, and the row before an output row is a round row. Neither says where a chain may open. A block could begin on a bare round row from a state the prover picked, run forward, and put its output on the bus with no input emit tying it to anything.

Cross-bus matching is a characteristic-two multiset check, which means a lone emit has to be balanced by something. The prover has two ways to arrange that. REQUEST_IDX is a free committed column, which lets two phantom blocks name the same partner row and annihilate pairwise, dropping an honest block's tail off the bus. Or aim the phantom block's output at a CPU row that expects a digest and let the CPU's own emit cancel it. Two rows suffice for the second shape: one round row carrying round(23) from a free state, then its output row.

The lever is stronger than the constant gap above, because the forged output needs no algebraic work at all.

Fixed by three roots that ride with the one-hot index:

cs.assert_zero_when(not_round, weighted(0, 24));
cs.assert_zero_when(not_round, weighted_next(1, 24));
cs.constrain(round(0) * (one + s_in_out));

A row that is not a round row carries no round bit at all, and its successor carries none above bit 0. The activity parity then pins round(0) on that successor whenever it is active, and the third root forces S_IN_OUT on any row carrying round(0). Every chain announces its input. The two-row stub dies on the first line: its round(23) bit cannot be set on a row whose predecessor is not a round row.

§ 3. Keccak: the bus key did not say which end of a block an emit was

The key was 25 lanes plus a request index. Both emit rows fire on S_IN_OUT; S_ROUND told them apart inside the AIR and was not a bus source. Swap the two request indices, run the block forward, and the consumer reads the result backwards. Inverting keccak-f costs one keccak-f, which makes the substitution free.

The chiplet proved its emitted multiset was closed under the 24-round map. It did not prove that the consumer's output was the image of the consumer's input. Pinning the round constants does not help here, because the block runs the canonical schedule in canonical order. In a sponge each call flips independently, which puts 2^calls digests within reach of one message.

Fixed by appending KeccakColumns::IS_OUTPUT, a committed Bit, to the key on both endpoints, pinned on the chiplet side by two roots. The second one is not optional:

cs.assert_zero_when(s_in_out, is_output + one + s_round);
cs.assert_zero_when(one + s_in_out, is_output);

Without it the column is free on non-emit rows, which is the one failure here that a single-bit mutation harness does catch.

§ 4. AES: a bare emit row needed no block behind it

One constraint carried the chain discipline:

cs.constrain(s_active * (cs.one() + next_s_active + next_s_in_out));

An active row must be followed by an active row or an emit row. Nothing constrained a row that was neither. A row with S_IN_OUT = 1 and every other selector clear satisfied every equation in the chiplet: the round, key schedule and counter constraints are gated on S_ROUND, S_FINAL and S_INPUT, and the off-gate pins reached only the key-schedule witness columns. STATE_IN on that row was free, and it is a bus source.

REQUEST_IDX_LINK is a free committed column, which again lets two such rows carry the same state and the same partner index and annihilate pairwise. Four rows are enough: one honest input emit, two decoys that cancel, and one carrying the ciphertext of the prover's choice. The block runs zero rounds past its input.

§ 5. AES: the round count was not pinned

ROUND_NUM started at 1 on the input row, doubled on every S_ROUND row, and was pinned to 0x36 on the S_FINAL row. The comment above it claimed this enforced exactly nine round rows before the final one. It did not, twice over.

A run need not reach S_FINAL at all. The chain constraint above lets an active row be followed by a bare emit row, which makes a two-row block a complete, AIR-valid witness computing MixColumns(ShiftRows(SubBytes(W))) + K1 and putting it on the bus as the ciphertext. One-round AES is trivially invertible, and a prover who must hit a chosen ciphertext solves backwards for the plaintext.

The counter also wraps. 0x02 has multiplicative order 51 in GF(2^8) under the FIPS 197 polynomial, which puts the AES-128 pin 0x36 at nine doublings and every 51 after that, and the AES-256 pin 0x4D at thirteen and every 51 after that. A sixty-round AES-128 block satisfies the counter pins exactly as a nine-round one does, and any chiplet trace tall enough for 61 rows admits it.

That height is not a hypothetical. Our own shipped AES-128 example runs 31250 blocks at 11 rows each, rounded up to a chiplet trace of 2^19 rows. A 61-row block fits inside it about eight thousand times over. The wrap was reachable on the geometry we ship, not only on a geometry an attacker would have to talk us into.

The mirror case is a run that never starts. The S_FINAL pin is absolute, a lone final row preceded by an idle row is valid, its ROUND_KEY is free because the key cascade only fires on S_ROUND and S_INPUT rows, and the emit row after it carries ShiftRows(SBOX_OUT) + ROUND_KEY.

Gaps 4 and 5 are fixed together by the same one-hot index that fixed Keccak. ROUND_NUM: B8 becomes ROUND_IDX: B16, expanded into 16 virtual bits. One pin clears the bits above the active range and four identities make every selector a function of the index:

cs.constrain(weighted(ACTIVE, 16));

cs.constrain(s_active + cs.sum(&(0..ACTIVE).map(round).collect::<Vec<_>>()));
cs.constrain(s_final + round(ACTIVE - 1));
cs.constrain(s_input + round(0));
cs.constrain(s_round + s_active + s_final);

Six more roots plus one shift per round carry the chain, and the induction closes. An idle row carries no round bits, a row following one carries at most bit 0, and the parity forces rb(0) = 1 if that row is active. Each shift carries the single bit forward and the parity forbids a second. An idle row cannot absorb a shifted bit, which stops a run ending early. Every maximal active run is exactly ACTIVE rows, opens on an input emit, closes on a final row, and is followed by exactly one output emit. There is no bare emit row and no short or long run. Rcon leaves the witness by the same route iota did.

We considered keeping the doubling counter and pinning ROUND_NUM = 1 on input rows. That needs an equality test on a B8, an inverse witness, three more columns, and it is fragile against the next person who changes the round count.

§ 6. AES: the link key did not say which end of a block an emit was

Identical in shape to gap 3, on a different chiplet, found after it. link_spec sources were 16 STATE_IN bytes plus a request index. Both the input row and the output row fire on S_IN_OUT. Swap the two request indices on a canonical block and the consumer reads its ciphertext where it expects its whitened plaintext.

The chiplet proved its emitted pair was related by the round function. It did not prove the direction. AES-128 is not an involution, at most one of the two labellings holds, and the verifier accepted both.

Fixed by appending S_INPUT to the key under AES_DIRECTION_LABEL on both levels. S_INPUT is a function of the one-hot index now, which is what stops it floating.

§ 7. AES: the S-box bus had no clock

The aes_sbox key was 16 state bytes plus 16 S-box bytes and nothing else. Encrypt the same block twice and every S-box emission has multiplicity two, which cancels the pair before cross-bus matching runs and leaves SBOX_OUT tied to nothing. The round equations consume it as an input:

let body = cs.next(state_in + j) + cs.col(round_key + j) + cs.sum(&mc_terms);
cs.assert_zero_when(s_round, body);

XOR a delta into SBOX_OUT[0] on the final round row of both blocks and the same delta into STATE_IN[0] of both output rows. SHIFT_MAP[0] = 0 carries it into ciphertext byte 0 unchanged. Every AIR equation holds, preflight reports zero violations, and both forged emissions cancel against each other while the honest ROM rows cancel among themselves. Two equal blocks in one proof is the entire precondition, and the attacker chooses which blocks to submit.

Both endpoints carried a waiver from the clock-stitching enforcement work. Its argument was that phantom blocks are caught at the link and key buses, which gaps 4 and 5 disprove, and its citation was hekate-chiplets/src/aes/aes128.rs, a path that had not existed since the crate was renamed.

Fixed with a real clock. The AES side appends Source::RowIndexLeBytes(4), the ROM commits a REQUEST_IDX: B32 column and appends the matching Source::Column, and trace generation fills it with the AES row index it is already iterating. No clock_waiver remains anywhere in the crate, on either level or on the ROM, and the cross-endpoint validator now sees a real clock instead of an argument. The AES side emits at most once per row and carries that row's index in the key, which makes its keys pairwise distinct. Each key must then appear an odd number of times on the ROM side, and every ROM appearance satisfies OUTPUT = S(INPUT).

Lookup kind was the other candidate and it is worse here. It needs both endpoints positionally aligned on the padded hypercube, and the ROM compacts active rows.

§ The half of the fix that lives in the host

A direction source on the bus binds the chiplet's two emits to each other. It says nothing about which row of the consumer's trace is the request. Leaving that to convention reopens gaps 3 and 6 by a second route: rehome the key emit alongside the swapped link indices and both buses balance again.

CpuKeccakUnit::constrain carries IS_OUTPUT[next] = IS_OUTPUT + SELECTOR, which alternates input and output in trace order and pins every cell of the column rather than only the off-selector rows. That recurrence is cyclic and the complement of a valid column also satisfies it. The complement is precisely the reversal, which is why direction_boundary anchors row 0 and why it is not optional.

CpuAes128Unit::constrain and CpuAes256Unit::{constrain, constrain_at} do the same job in five roots:

cs.assert_boolean(sel);
cs.assert_boolean(dir);
cs.constrain(dir * (one + sel));
cs.constrain(sel * (dir + next_dir + next_sel));
cs.constrain(next_sel * (one + sel) * (one + next_dir));

No boundary constraint is needed there, because the run-opener root anchors through the trace-end wrap where Keccak's bare recurrence does not.

Leaving the direction column free on emit rows is the whole bug. A host that pins direction from its own state can constrain it itself. A host that writes only the receiving row has not fixed anything, and nothing at the API level forces a caller of linking_spec_at to also call constrain_at, because the two live in different trait methods and a host can always hand permutation_checks a throwaway ConstraintSystem. That coupling is out of reach of the type system. It is closed from the test side instead, by hekate_scribble::language::assert_direction_pinned.

§ Why the test suite was green

Thirty exploit tests in hekate-aes/tests/aes_chiplet.rs tested the constraint evaluator and not the AIR. Every one of them tampered a cell inside an otherwise honest trace:

set_bit_val(&mut traces[0], Aes128Columns::S_ROUND, 4, Bit::ZERO);

Clearing S_ROUND alone breaks s_active = s_round | s_final, which the AIR already enforces. The test passes, and it reads as round-count coverage. It never lays a witness that is consistent under the shortened schedule, which is the only shape an attacker would ever build. The Keccak suite had the identical pattern: exploit_rc_tamper flipped one constant bit and asserted rejection, which the Iota constraint catches because the state chain stops matching, while a chain laid consistently under a substituted schedule sailed through.

A tamper test that breaks a relation the AIR already enforces is evidence that the AIR enforces that relation. It is not evidence that a column is bound.

The mutation harness was green for a related reason. hekate-scribble's FlipSelector strategy flips one selector at a time, and every single-bit flip lands on an identity the AIR already carries. All seven gaps need two or more coordinated changes to the witness.

The tamper helpers themselves were also wrong. flip_b8 and flip_b64 wrote through Flat::from_raw, skipping the tower-to-flat basis map, which lands a named delta on an unrelated value. A test that says it corrupts byte 0 and actually corrupts something else still passes, for the wrong reason, and reports coverage it does not have.

And the waiver. Our validator checks that waiver text starts with "see " and runs at least 32 characters. It does not check that the citation resolves, and it cannot check whether the argument is still true. The AES waiver failed both of those and passed the one we automated.

§ How the fix is checked

We stopped arguing about the language an AIR admits and started enumerating it. The one-hot index itself is not new mathematics; the check around it is the part worth copying.

hekate-scribble gained a language module. It holds every data column at zero, evaluates only the roots whose column set lies entirely inside the control plane, and returns the transition core after dropping states with no successor or no predecessor. Roots that mix control and data are skipped, which makes the enumerated relation a superset of the AIR's real one. A core that equals the honest automaton therefore bounds the real language from above, which is the direction that matters.

• AES-128, all 2^16 index values: 770 candidate row states, and the core is exactly idle -> I R^8 F -> O -> idle.
• AES-256, same enumeration at 14 active rows: 12290 candidates, same shape.
• Keccak: the index is 24 bits wide and the ordered pairs that come with it put exhaustion out of reach. The enumeration is bounded to Hamming weight 3, which covers the one-hot plus every single skipped or duplicated shift: 1797 candidates, core equal to the honest automaton. That is a bound and not a proof, and the test states it as one.
• assert_direction_pinned rejects any host AIR admitting more than idle -> request -> response -> idle. Two deliberately weakened hosts sit in the suite and both are rejected, one carrying nothing but the two boolean roots and one missing the run opener.

That covers four of the seven gaps and one half of two more. The enumeration catches 1, 2, 4 and 5, because a substituted schedule and a malformed run are both properties of the transition relation and that relation is exactly what it walks. assert_direction_pinned catches the host half of 3 and 6.

Nothing new catches the chiplet half of 3 and 6, or any part of 7. A source missing from a bus key is not a property of the transition relation, and an enumeration of the control language will happily report a perfect automaton for a chiplet whose emissions are indistinguishable to the verifier. We found those three by reading the key construction and asking what a second emission with the same key would mean. That is not a method, it is an afternoon and a suspicious mood, and it does not survive the next person or the next chiplet.

The tool that would catch them does not exist here yet. It would enumerate the sources of each bus key against the properties that must be bound for that bus: which endpoint owns the clock, whether two emissions from the same table can collide on the key, whether the key distinguishes emissions the AIR treats differently. Our validator already asks the first of those three, which is how the clock waiver came to be written at all. It does not ask the other two.

Each AES forgery also pins attribution before the verdict. assert_air_violated where the rejection must come from a constraint root, assert_air_clean where it must come from the bus. Before the fix, all of them passed preflight with zero constraint violations and zero boundary violations, which puts the acceptance on the chain discipline and the bus rather than on a broken harness. Two were clean on the preflight bus diagnostic as well: both endpoints emitted the same multiset and even the product-based debug oracle saw nothing.

One test isolates a single root. direction_pin.rs builds a host carrying four of the five roots constrain emits, and it accepts a proof in which two identical blocks cancel their own input and key emits, handing the consumer a ciphertext that no row of its trace bound a plaintext or a key to. The same witness under the full five is rejected on a constraint root. Without that test the language enumeration above would be a model with nothing anchoring it to exploitability.

§ What correctness cost

Row width moves 3 bytes down on Keccak, 1 byte up on AES-128, 1 byte down on AES-256, and 4 bytes up on the ROM. Trading 64 constant columns for a 32-bit index made the Keccak row smaller while making it correct, which is the pleasant case and not the general one.

End to end, against 0.32.0. Signed public cdylib 0.10.0, table-math, Apple M3 Max, -C target-cpu=native, mean of three runs, peak memory as phys_footprint_peak:

Binding a round schedule is close to free, unlike the two fixes before it. Prove time moves within 6%, every proof size lands within 1% of its 0.32.0 figure, verify is unchanged at 6 to 36 ms, and peak memory is flat inside the variance of a polled measurement. The two Keccak rows move most, and the reason is legible: the chiplet gave up 3 bytes of row and took on 33 more constraint roots, and at 2^20 the roots cost more than the narrower row saves. AES pays 3% for 11 and 8 more roots.

Nothing in the wire format, Config, or transcript ordering moved for these two fixes. The cost that matters is program_id: every program embedding either chiplet gets a new one, and every existing proof has to be re-proved.

§ The commitment layout, in the same release

The numbers above are the chiplet fixes measured alone. 0.33.0 also carries a change to the Brakedown commitment layout, and the rest of this section is that change rather than a soundness gap.

The commitment used to encode every physical column twice, once as-is and once shifted by one row, because the evaluation argument had to open the shifted polynomial at the same point. The second copy is gone. Shifted claims are now proven through weights the verifier evaluates for itself: a carry-chain form of eq(prev(·), P) paired with the whole-column master, and its ring-switch counterpart paired with the bit-plane master. Same hash, same code, same Merkle structure, half the codeword. The wire format moves to v4 and no 0.32.0 verifier accepts a v4 proof.

Binding does not move with it. The second copy was another opening of data the first copy already committed, never an independent constraint, and the weight replacing it is transparent: the verifier evaluates it from the point and its own sumcheck challenges, leaving the prover nothing to choose.

Measured the same way, signed public cdylib 0.11.0, peak memory as the larger of phys_footprint_peak and ru_maxrss, because sampling misses a peak reached between polls and the compressor caps the other under pressure:

Proof size falls 20 to 29% and peak memory 13 to 31%, for one reason in three places: a byte the commitment no longer carries is a byte not encoded, not hashed into the tree, and not opened at a query. Verification stays flat at 6 to 32 ms, because the verifier trades two opened halves for two weight evaluations it computes in O(n).

The prove column is not the layout alone, and the proof column is. Nothing else in this release moves proof bytes. Prove time carries two further changes landing in the same window: hekate-math 0.10.0, whose NEON flat multiply kernels move to the vector domain and take Block128 dependent-chain latency from 7.27 to 4.64 ns/mul with a 12% end-to-end gate, and prover-internal work that is not described here, the prover being a closed-source cdylib. The three are not separated by measurement, and reading the whole column as the commitment layout would overstate it.

This is the first change in the sequence that gives cost back rather than spending it. It is also the only one a reader should not treat as mandatory: the three fixes before it bought soundness, and this one bought bytes.

§ The bill for the whole sequence

The table above isolates one change. This one stacks all four. Against 0.29.1, the last release measured before any of the protocol fixes, with a derived code distance, a committed h, a bound schedule and the new layout all underneath it:

All six prove faster today than they did before any of this existed, AES included. Through 0.32.0 that was true of four, and AES ran 27 to 30% slower as the most commit-bound workload in the set; halving the codeword is worth most exactly where commit dominates.

Proof size did not come all the way back. Against 0.30.0, the smallest we ever shipped, ML-KEM-768 is up about 27%, ML-DSA-65 26%, ML-DSA-87 34%, and AES-128 97%. Through 0.32.0 those same four stood at 58%, 67%, 79% and 169%. What remains is the standing price of a proximity layer whose distance is derived rather than assumed, and of a bus helper that is committed rather than reported. We would rather pay it there than in the number it replaced, which was a 54% acceptance rate against the real verifier.

Both cross-release comparisons are separately-taken measurement sets on the same M3 Max rather than one controlled run, and the 0.29.1 figures were taken on an older prover build.

§ For other implementers

Count your roots against your columns. Keccak's root count was 25 + 1600 + 2 + 2 and none of those roots touched the 64 columns holding the round constants. That was arithmetic, available at any point over the life of the chiplet, and nobody did it. A committed column that no root reads is an input from the adversary.

A constant in a witness column is a free variable. Fold constants into coefficients, which keeps them out of the trace entirely. Both chiplets now carry their round constants as scalars multiplying a one-hot selector, and there is nothing left for a prover to choose.

Write down the property you assumed and never stated. Three of these gaps are a missing block boundary and three are a missing field in a bus key, and both groups are that one omission. Transition constraints describe a well-formed block from the inside, and where a run may open and that it must close are separate statements you have to make. A bus key is the whole interface, and anything not in it is not proved about the emission, where in characteristic two an emission that collides with another is not weakly bound but deleted. In all six cases the property was real, the designer knew it, and it never became a root or a source.

Tamper tests are not soundness tests. Breaking a relation the AIR enforces demonstrates that the AIR enforces it. The witness an attacker builds is consistent under the substitution, and it is more work to construct. Build that one. If your suite has thirty exploit tests and every one of them mutates a single cell of an honest trace, you have thirty tests of your constraint evaluator. The same goes for any check whose form you automated and whose content you did not: our clock waiver had to begin with "see " and run 32 characters, and it did, while its citation pointed at a file deleted months earlier and its argument had already been refuted by two other gaps in the same chiplet.

Enumerate what you can, and publish what you cannot. If the control plane of your circuit is small, hold the data at zero, walk every state, and compare the admitted transition relation against the automaton you meant to build. A superset that matches the honest automaton is a real bound and it is a few hundred lines. Then publish what it does not reach, in the same document that claims it. Ours does not reach bus keys, which is where three of our seven gaps were.

§ Scope

This postmortem covers hekate-keccak, hekate-aes, hekate-pqc and hekate-scribble, all of which are open, along with the CPU-side interfaces hosts build against. The wire format, transcript and verifier protocol are unchanged from 0.32.0. The prover reaches this workspace as a signed cdylib from a closed repository; soundness here is a property of the AIR and the bus, both public, and every forgery above runs through the real prover and the real verifier rather than against a mock oracle. Which of them were also run against a pre-fix build is recorded in the summary.

The previous postmortem is at postmortem-0.32. Its four lessons still hold, and this release adds a question they do not ask. That document audited every value entering the final verdict and found three that nothing bound. It never asked whether the witnesses satisfying our circuits were the witnesses we meant to admit. Those are different questions, and the second one needs a different tool.
